PILLAR TYPE POWER PRESS   Pillar Type Capacity   25 KPR 25 KRI 32 KPS 38 KPL 38 KPF Size of Machine 25 25 32 38 38 Length of Bed - - - - - Width of Bed 280 11 305 12   Spindle Spindle Travel 150 200 250 300 150 Spindle Taper MT-3 MT-3 MT-3 MT-4 MT-4 No. of Spindle speed 8 8 8 8 10 Range of Spindle speed 115-2820 115-2820 115-2820 70-1910 100-2700 No. of feed Fineleed Fineleed Fineleed Fineleed 1 Feed vlue m.m/rev. - - - - 0.3 Working Range Column Diameter 87 87 112 112 112 Max. distance between spindle centre to column face 255 378 270 270 260 Min. distance between spindle centre to column face - - - - - Max. distance between spindle nose to baseplace 1060 1060 100 ND ND Min. distance between spindle nose to baseplace 655 655 565 ND ND Verticle movement on column railarm - - - - - Working surface of table 350x350 400x400 375x375 ND ND Working surface of baseplate 580x365 695x375 700x430 700x430 ND Electric Motor for arm elevating - - - - - Electric Motor for drilling head 1 Hp 1 Hp 1 Hp 1.5Hp ND Nett Weight of the machine 224 kg 300 kg 325 kg 350 kg ND
